MTP to MTP (Low Loss) Female 12 Fibers OM4 OFNP Multimode Trunk Cable

In stock - 20 items available
Cart Image PN: ZMTEFLEABBB0102
Cart Image Inventory quantity: 20
  • Low loss design for long-distance transmission
  • 12-core OM4 fiber, ideal for high-density installations
  • Durable OFNP jacket, suitable for data centers and cabling environments
  • Available Options: 1m, 2m, 3m, 5m, 10m / Customized
  • Contact us for more info

ZMTEFLEABBB0102

20

Unit Price:
Regular price $3,520.00 TWD
Total Price:
$3,520.00

Lead time: 2-3 workdays for In-Stock items

Special Orders

  • Delivery time 4-8 weeks for Special Orders

Product Description

MTP to MTP (Low Loss) Female 12 Fibers OM4 OFNP Multimode Trunk Cable

The MTP to MTP (Low Loss) Female 12 Fibers OM4 OFNP Multimode Trunk Cable ensures high-speed data transmission with minimal insertion loss. Its low-loss performance and bend-resistant design make it ideal for dense fiber installations and long-distance connections. This cable supports 850/1300nm wavelengths and is protected by a durable OFNP-rated jacket, ensuring reliability even in challenging environments.


In Stock: 10m
Available Options: 1m, 2m, 3m, 5m, 10m / Customized
(The actual product received shall prevail.)

FEATURES

Connector A MTP Female Connector B MTP Female
Fiber Type OM4 50/125um Polish Type APC to APC
Fiber Count 12 Fibers Jacket Material PVC OFNP
Return Loss >=25dB Insertion Loss <=0.35dB
Wavelength 850/1300nm Storage Temperature -40 degree Celsius ~ 80 degree Celsius
Operating temperature -10 degree Celsius ~ 70 degree Celsius Installation Tensile Load 66N
Long-Term Tensile Load 50N Jacket OD 3.0mm
