CAT6A 28AWG 10G Cable - FlexLite™ U/FTP OD 5.0mm 500MHZ LSZH & SOFT PVC
- Ideal for high-speed applications up to 10 Gbps
- 40% tighter in cable bend radius for flexible cabling routing in tight space, thus improving airflow
- 65% smaller in bundle size for rack installation
- Environmentally friendly with Low Smoke Zero Halogen (LSZH) jacket & Soft PVC jacket available
- In-house designed clear tab snagless molded RJ45 connectors for snug fit and maximum bend radius
- TAA Compliant
- Custom colors, options, and lengths are available upon request
- 11 Colors Available: Aqua, Black, Blue, Green, Grey, Orange, Purple, Red, White, and Yellow
MM-S6AJ-0.5-28PVC-F
300
Lead time: 2-3 workdays for In-Stock items 寄達台灣需要6-7週
Special Orders
- Delivery time 4-8 weeks for Special Orders
Our FlexLite CAT6A U/FTP 28AWG Patch Cord Series is a compact, lightweight CAT6A design with these differentiating advantages:
- 40% smaller in cable outer diameter for efficient rack airflow and higher cable bundle density
- 40% better in bend radius for maximum cable routing flexibility
- Snagless plug with strain relief boot for maximum durability
- Stable performance with passing performance tests for wire map, NEXT and return loss
- Environmental friendly IEC60332-1-2 flame test ratings and Low Smoke Zero Jacket (LSZH) classification
- Aqua, Blue, Green, Grey, Orange, Purple, Red, White, and Yellow in LSZH jacket
- Black, and Orange in Soft PVC jacket
The FlexLite CAT6A U/FTP cables are made of 28AWG with 100% stranded copper wires as opposed to copper clad aluminum (CCA). They support up to 500 MHz for LSZH Jacket and 550MHz for Soft PVC Jacket. The connectors use T568B pin assignments. The FlexLite CAT6A U/FTP cables are Fluke passed and certified. The test results are available upon request.
We offer a broad portfolio of the FlexLite Ethernet cables. Please check our product comparison table for details.
Custom Options
We offer custom lengths, additional colors, and order quantity discounts. Please contact us for details and pricing.
We also offer service to label and bundle cables to simplify the cable installation of your data center projects
Length: 0.5 FT
Customization: Custom length, custom color
Optional Services: Single label (or multiple labels) per cable, single label (or multiple labels) per bundle, JIT (just-in-time)
Logistics / Shipping: Special shipping instructions, special packaging instructions, drop shipment, international shipment, will call arrangement, trucking arrangement
Cable type: Category 6A
Outside dimension: 5.0 mm +/- 0.3mm (diameter) for LSZH Jacket
Outside dimension: 5.2 mm +/- 0.3mm (diameter) for Soft PVC Jacket
Jacket material: LSZH, Soft PVC
Conductor Gauge: 28 AWG
Conductor construction: Stranded copper wires
Cable Performance: Up to 500MHz for LSZH, 550MHz for Soft PVC
Cable shielding: No overall shielding or braid (U) with foil screened twisted pairs (FTP)
Connector wiring: T568B
Connector type: Sentinel® RJ45 clear connector
Certifications: UL Code 444, EIA/TIA-568-C.2, UL & cUL E495789
Installation temperature: 0°C to 70°C
Operation temperature: -10°C to 70°C
RoHS compliant: Y
